We are Riddhi Siddhi Impex, a Mumbai-based supplier and stockist of Nickel 200 Coils, founded in 2002. We keep commercially pure nickel coils to ASTM B162 / ASME SB-162 on the shelf in 0.03 mm to 5 mm gauges. Our ISO 9001, 14001, and 45001-certified firm holds a monthly supply capacity of 400-500 tons and ships with EN 10204 Type 3.1 / 3.2 mill test certificates on request.
Nickel 200 coils are continuous wound lengths of commercially pure wrought nickel, a grade holding 99.0% minimum nickel content. UNS N02200 melts across the 1435-1446 °C range and carries a density of 8.89 g/cm³. The metal resists caustic alkalis and reducing acids, stays ferromagnetic at room temperature, and serves continuously up to about 315 °C, a ceiling set by its 0.15% maximum carbon. It cannot be strengthened by heat treatment; cold working is the only effective method. It is widely used in food processing and pharmaceutical equipment.
Material dispatches annealed to ASTM B162 in any width from 3 mm to 2000 mm, with the buyer's choice of finish and edge, and a mill test certificate travels with every consignment on request.
We provide ASTM B162 Nickel Coils in annealed mill condition, available across six surface finishes and four edge options, slit to width from ready Mumbai stock.
| Parameter | Details |
|---|---|
| Standard | ASTM B162 / ASME SB-162 |
| Thickness | 0.03 mm to 5 mm |
| Width | 3 mm to 2000 mm |
| Coil ID | 150 mm to 610 mm |
| Coil OD | Up to 1800 mm |
| Condition | Annealed (standard mill) |
| Supply Form | Hot Rolled and Cold Rolled |
| Surface Finish | BA (Bright Annealed), 2B, Scotch-Brite, Matte, Matte PVC, Skin Pass |
| Edge | Slit edge, Mill edge, Deburred edge, Round edge |
Commercially pure nickel coils mainly consist of nickel. ASTM B162 sets a 99.0% floor, and the 0.15% maximum carbon fixes that 315 °C service ceiling.
| Element | Composition (%) |
|---|---|
| Nickel + Cobalt (Ni + Co) | 99.0 min |
| Carbon (C) | 0.15 max |
| Manganese (Mn) | 0.35 max |
| Iron (Fe) | 0.40 max |
| Silicon (Si) | 0.35 max |
| Copper (Cu) | 0.25 max |
| Sulphur (S) | 0.010 max |
Annealed Alloy 200 Coils pair modest strength with unusual ductility, so the strip presses, spins, and deep-draws freely. Values for gauges under 1.59 mm stay indicative.
| Property | Value (Annealed) |
|---|---|
|
Tensile Strength, minimum
|
380 MPa (55 ksi) |
|
Yield Strength (0.2% offset), minimum
|
105 MPa (15 ksi) |
|
Elongation in 50 mm, minimum
|
40% |
International buyers can cross-check UNS N02200 Coils against their regional designation in the table below. The W.Nr 2.4060 coils we hold in stock answer every listing shown.
| Country / Standard | Designation |
|---|---|
| USA (UNS) | N02200 |
| Europe (EN) | 2.4066 |
| Germany (W.Nr) | 2.4060 |
| Japan (JIS) | NW 2200 |
| China (GB) | N6 |
| UK (BS) | NA 11 |
| Russia (GOST) | НП2 |
These 3 industries use the Ni 200 coils we slit. Buyers in each pick the grade for chemical stability, conductivity, or magnetic behaviour rather than structural strength.
Caustic soda producers form Nickel 200 coil into heating elements, evaporator strips, and tank linings. The grade holds its surface in sodium hydroxide at every concentration, where stainless steel suffers caustic cracking. Chlor-alkali cells and salt works run the same material through drying and electrolysis stages for identical reasons.
Transducer and sensor makers specify Ni 200 coil for parts that must be both ferromagnetic and magnetostrictive; the strip changes length measurably in a magnetic field, and ultrasonic stacks apply exactly that behaviour. Battery makers slit the same coil into tabs and terminals, drawing on thermal and electrical conductivity well above most nickel alloys.
Dairy, beverage, and pharmaceutical fabricators line product-contact surfaces with CP Nickel Coils because the metal releases no contaminating ions into the process stream. Hot alkaline clean-in-place cycles pass without attack. Mixer baffles, sieve frames, and dosing components hold their dimensions through years of washdown duty.
As a Nickel 200 Coils supplier and exporter, we pack every order at Mumbai and Taloja for sea transit.
| Parameter | Details |
|---|---|
| Packaging | Wooden cases, pallet packing |
| Incoterms | FOB, CIF, CFR, EXW Mumbai |
| Dispatch Points | Mumbai and Taloja warehouses |
| Standard Lead Time | 4 to 5 days |
| Urgent Dispatch | 2 to 3 days |
| Payment Terms | Advance, credit, LC |
| Certification | EN 10204 Type 3.1 / 3.2 on request |
Nickel 200 Coils price in India is around 2,100-₹2,200 per kg, roughly $30 to $48 for export buyers. The price per kg follows LME nickel, and thickness, width, finish, and order volume all shift the final figure. Bulk and wholesale orders draw discounts, so call or WhatsApp us for today's rate.
We supply Nickel 200 coil in thicknesses from 0.03 mm to 5 mm, slit to any width between 3 mm and 2000 mm at ±0.1 mm. Requirements thinner than 0.03 mm move to our Nickel 200 foils range.
Nickel 200 coils are covered by ASTM B162 and its ASME twin SB-162, which specify nickel plate, sheet, and strip; a coil is a strip supplied wound. Aerospace orders can also call up AMS 5553.
Yes, Nickel 200 coil is ferromagnetic at room temperature and doesn't lose that behaviour until its Curie point around 360 °C. Transducer, relay, and sensor builders use the property directly.
The maximum service temperature for Nickel 200 coils is about 315 °C. Above that, carbon at up to 0.15% precipitates as graphite along grain boundaries and embrittles the metal, so specify Nickel 201 coils, capped at 0.02% carbon, for hotter duty.
Yes, Nickel 200 coils can be used for caustic soda handling and remain the standard pick for heating coils, evaporators, and storage vessels in NaOH plants. Keep metal temperature below 315 °C and the grade serves across the full concentration range.
You can source Nickel 200 Coils in India from us at Riddhi Siddhi Impex. Our Mumbai warehouse holds UNS N02200 coils on the shelf for immediate dispatch, and as a Nickel 200 coil supplier, stockist, and distributor, we serve dealers, wholesalers, and end users across India and overseas. Phone or WhatsApp us; get a quote within 24 hours.
